GENERAL PURPOSE
Fast industrialisation has required the utilization of transport lines which have ended up being the most savvy framework for transportation of unrefined substance and completed products in any structure, for any application.
MODIPLUS belting are made in our most current, completely robotized plant, utilizing the best unrefined substance inputs, under the severe vigil of qualified specialized work force. Our Belts have found palatable clients in the Domestic
and the International commodity market with our customer base running Iron and Steel Plants, Coal, Copper, Gold Mines, Cement Plants, Thermal Plants, Fertilizers Plant and Ports to give some examples. Modi Trading Conveyor Belts
adjust to all significant Indian/International Standards and are made in a wide reach to suit all applications.
Unique FEATURES
·
Special Carcass Construction
·
Predominant Adhesion Levels
·
Further developed Flex Life
·
Low Belt Stretch
·
Magnificent Impact Resistance
·
Further developed Resistance to Mechanical Damage
·
Mold, Moisture and Rot Resistance
·
Further developed Resistance to Ozone and Ultra Violet Radiation
·
Further developed Efficiency of Joints
·
Further developed Tear Resistance and Excellent Troughability
·
Appropriate for all Applications
GENERAL LIGHT DUTY SERVICE
Normal References : DIN – Z :
Exceptionally affordable for respectably rough/little size material.
MEDIUM ABRASION RESISTANCE
Normal Reference : DIN - Y, N, RMA 2, BS - N 17, AS - N, JIS - G :
Suggested for moderate scraped spot obstruction applications, for the most part over the ground. Routinely utilized for transportation of Coal, squashed metals, limestone, bauxite, sand, concretes and so on…
HIGH ABRASION RESISTANCE
Normal Reference : DIN - X, M, RMA 1, BS - M24, AS - M, JIS - S :
Astounding scraped area opposition against cutting, gouging, weighty effect, during transportation of weighty rocks, sharp stones and profoundly grating materials.
SUPER ABRASION RESISTANCE
Normal Reference : DIN - W :
Suggested in very rough applications like Copper and gold metal, sinter, coke. It gives high opposition without expanding cover thickness and weight of the belt. Oil Resistant (OR) and Moderately Oil Resistant (MOR) :
Explicitly utilized for transportation of explicit materials with high/moderate convergence of creature or vegetable fats. The extraordinary compound utilized in the covers, dodges harm/enlarging of belt additionally during transportation of material with pine oil, wood oil, olive oil, oil and so forth…
CHARACTERISTICS
| CHARACTERISTICS | MIN. TENSILE STRENGTH | MIN. ELONGATION | MAX. ABRASION LOSS | |
|---|---|---|---|---|
| kg/cm2 | Ibs/in2 | % | mm3 | |
| General Light Duty Service | > 150 | > 2130 | > 400 | < 250 |
| Medium Abrasion Resistance | > 190 | > 2700 | > 450 | < 200 |
| High Abrasion Resistance | > 240 | > 3410 | > 500 | < 120 |
| Super Abrasion Resistance | > 180 | > 2560 | > 400 | < 90 |
| STRENGTH CLASSES AND NO. OF PLIES | |||||
|---|---|---|---|---|---|
| Strength Class (KN/m) | 2-Ply | 3-Ply | 4-Ply | 5-Ply | 6-Ply |
| 160 | 160/2 | ||||
| 200 | 200/2 | ||||
| 250 | 250/2 | 250/3 | |||
| 315 | 315/2 | 315/3 | |||
| 400 | 400/2 | 400/3 | 400/4 | ||
| 500 | 500/3 | 500/4 | 500/5 | ||
| 630 | 630/3 | 630/4 | 630/5 | 630/6 | |
| 800 | 800/3 | 800/4 | 800/5 | 800/6 | |
| 1000 | 1000/3 | 1000/4 | 1000/5 | 1000/6 | |
| 1250 | 1250/3 | 1250/4 | 1250/5 | 1250/6 | |
| 1500 | 1500/4 | 1500/5 | 1500/6 | ||
| 1600 | 1600/4 | 1600/5 | 1600/6 | ||
| 1800 | 1800/4 | 1800/5 | 1800/6 | ||
| 2000 | 2000/5 | 2000/6 | |||
| 2500 | 2500/5 | 2500/6 | |||
